Product Introduction
XLT-12-123 is an electrochemical PPM oxygen sensor that exhibits good stability and accuracy under strict application conditions. All oxygen sensors have undergone extensive stability testing, with output in air, 30 "water column pressure testing, and stability under 100% oxygen.
Product parameters
Technical Specifications
Measurement range 0-100% O2
Signal output 590-950 µ A
Response time 90% 3
Accuracy of the entire scale+1%
Accuracy of FS within the scope of work (3)+5%
Non condensing humidity 0-99% RH
Temperature coefficient 2.54%/C
Working temperature 0-45 ° C
Constant operating pressure 5-30 PSIG
Current Speed. 1-10 LPM
Expected lifespan of 12-24 months
Storage from 0 to 40 ° C
Warranty for December
Electrical connection Molex connector
Recommended storage time<6 months
Product Application
application
Oxygen analyzer replacing electrochemical principles
